Air Louvers VSIG ArmrShield™ ARM3 Vision Lite Pak
Air Louvers VSIG ArmrShield™ ARM3 Vision Lite Paks are high-security commercial door glazing assemblies that combine a Slimline™ IG vision lite frame, 1-5/16″ ArmrShield™ Level 3 ballistic glazing, and glazing tape into a complete, ready-to-install system.
- Complete assembly including frame, glass, and glazing tape
- UL 752 Level 3 ballistic-resistant glazing
- Designed for 1″ – 3″ commercial door applications
- 20 gauge steel Slimline™ IG vision lite frame for thick glazing
- 1-5/16″ ArmrShield™ multi-layer security glazing
Product ID: VSIG ARM3 PAK
FREE delivery to most businesses and jobsites on qualifying orders.
Most orders ship within 3-5 business days. Get a quote now.
HOW TO ORDER
- Get a written quote from a USA Fire Door Solutions Specialist
- Approve & we ship your order
- Click the button below or call us to get started. You can upload plans, photos or files if you have them.
Product Details
Air Louvers VSIG ArmrShield™ ARM3 Vision Lite Paks provide a complete high-security glazing solution for commercial hollow metal doors and commercial wood doors requiring advanced ballistic resistance and impact protection. Each pak includes a Slimline™ IG vision lite frame, ArmrShield™ ARM3 multi-layer polycarbonate laminate glazing, and compatible glazing tape, ensuring proper component compatibility and simplified installation. The VSIG frame design accommodates thick security glazing while maintaining a clean architectural appearance and durable construction. ArmrShield™ glazing provides resistance to ballistic impact and forced entry, making this system suitable for government facilities, detention centers, schools, and other high-risk environments where maximum protection and visibility are required.
Specifications
Assembly type: Vision lite frame, glass, and glazing tape packaged together
Vision lite model: VSIG Slimline™ for insulated and thick glazing
Application: Commercial wood doors and commercial steel doors
Door thickness: 1″ to 3″
Frame material: 20 gauge cold rolled steel
Frame profile: Slimline™ IG design for thick glazing applications
Standard finish: Mineral bronze powder coat
Glazing type: ArmrShield™ ARM3 multi-layer polycarbonate laminate
Glass thickness: 1-5/16″
Glazing compatibility: Supports 3/16″ to 1-11/16″ glazing ranges
Ballistic rating: UL 752 Level 3
Glass performance: Impact safety rated (CPSC Category I & II)
STC rating: 37
Glazing tape: Compatible glazing tape for thick security glazing
Minimum size: 4″ × 4″
Maximum size: Based on door and glazing configuration
Fire classification: Non-fire-rated security glazing assembly
Installation: Integrated system for commercial door applications
Compatible doors: Hollow metal and solid core wood commercial doors
