Customizable Door Window Kits

Add a window to steel or wood flush doors. Order door lite kits with impact-safe tempered glass, security wire glass or fire-rated glass. Door lite kits include a metal vision lite frame and glass or glazing material that’s approved for commercial use. We supply custom sizes, custom finishes, volume based discounts and more. Work one on one with a commercial door and glass specialist. Contact us for a quote.

Door Lite Kit Types

Metal Door Window Kit, Clear Glass - USA Fire Door

Tempered Glass Door Lite

Tempered glass door lite kit with 1/4″ CAT 1 & 2 impact-safety glass for commercial doors.

Contact Us for Quote

USA Fire Door - Fire-Rated Door Window Kit

Safety-Wire Glass Door Lite

400 ft-lb impact tested wire glass door lite kit. Fire-rated up to 90 min.

Contact Us for Quote

Metal Door Window Kit, Clear Glass - USA Fire Door

Fire-Rated Glass Door Lite

Fire-rated glass door lite kit with fire rated glass ceramic and fire-rating up to 3 hr.

Contact Us for Quote

Metal Door Window Kit, Clear Insulated Glass Unit - USA Fire Door

Insulated Glass Door Lite 1"

Sealed, insulated glass door lite with 1/4″ tempered glass and 1″ total thickness.

Contact Us for Quote

Metal Door Window Kit, Acid Etch Frosted Glass - USA Fire Door

Frosted Glass Door Lite

Acid-Etched, “frosted” glass door lite kit with 1/4″ tempered impact-safety glass.

Contact Us for Quote

Keraliteยฎ, Schott Pyran Platinum Fยฎ, clear laminated glass and white-laminate glass options are also available. Not all sizes and products are available for quick shipment. Contact us for quotes and info.

๎€‡

Get the best pricing and service.

Save time & money. Call now or contact us to work with a commercial door specialist. We supply commercial door projects of all sizes.

Glass Door Lite Options

Fire Protective Glass: Fire protective glass is a designation of fire-rated glazing for commercial windows and doors. Fire protective glass is used as a barrier against flames, smoke and toxic gasses to allow building occupants time to escape. Although fire protective glass blocks flames, it is not a barrier to radiant heat. Because it is not a barrier to heat transfer, fire protective glass can only be used within strict size limitations.

Human-Impact Safety Glass: Human-Impact safety glass is designed for use in commercial buildings where incidental impact may occur. Human impact safety glass is usually thicker, harder, and more impact resistant than conventional glass products.

Fire-Rated Glass with Safety Film: Safety-filmed fire glass is produced by fusing safety film to the glass during manufacturing. This process strengthens the glass, makes it more resistant to impact, and allows the glass to remain intact when exposed to fire for a specific period of time.

Safety-Filmed Wire Glass: Safety-filmed wire glass is produced by fusing safety film to the wire-embedded glass. This process strengthens the glass, makes it more resistant to impact, and allows the glass to remain intact when exposed to fire for a specific period of time.

  • PPFย  – Pyran Platinum F: Fire-Rated Glass โ€“ Pyranยฎ Platinum F safety filmed, fire protective glass ceramic for commercial door lites.
  • KFRF – Keralite: Fire-Rated Glass โ€“ Keraliteยฎ fire protective glass ceramic with human impact safety film for commercial door lites.
  • Safety-Wire Glass: Fire-Rated Glass โ€“ Architectural glass with embedded wire mesh for commercial and fire rated windows and doors lites.
  • PPL – Pyran Platinum L: Fire Rated Laminated Glass โ€“ Pyranยฎ Platinum L laminated, fire protective glass ceramic for commercial door lites
  • Temp x PFF IGU 1″: Insulated Fire-Rated Glass โ€“ Pyranยฎ Platinum F safety filmed glass ceramic & tempered glass โ€“ One Side Fire Protection.
  • Pyranยฎ PPF x PFF IGU 1″: Insulated Fire-Rated Glass โ€“ 2 sheets of Pyranยฎ Platinum F safety filmed glass ceramic โ€“ fire protection from both sides.
  • 1/4″ Tempered Glass – Impact safe tempered glass window kit for commercial door lites.
  • 1″ Insulated Glass –ย  Insulated glass window kit for commercial doors, made with 2 sheets of 1/4″ glass and 1″ total thickness.
  • Frosted Glass – Acid etched, frosted glass window kit for commercial doors
  • Clear Lami – Clear laminated glass window kit for commercial doors with (2) sheets of 1/8″ glass fused together with clear interlayer.
  • White Lami – Clear laminated glass window kit for commercial doors with (2) sheets of 1/8″ glass fused together with opaque white interlayer for privacy.
  • 20 Minute Fire-Protective Glass: When used within size limitations, 20 minute fire protective glass is approved for use in commercial window and door assemblies. Fire-protective glass is not a barrier to radiant heat.
  • 45 Minute Fire-Protective Glass: When used within size limitations, 45 minute fire protective glass is approved for use in commercial window and door assemblies. Fire-protective glass is not a barrier to radiant heat.
  • 60 Minute Fire-Protective Glass: When used within size limitations, 60 minute fire protective glass is approved for use in commercial window and door assemblies. Fire-protective glass is not a barrier to radiant heat.
  • 90 Minute Fire-Protective Glass: When used within size limitations, 90 minute fire protective glass is approved for use in commercial window and door assemblies. Fire-protective glass is not a barrier to radiant heat.
  • 3 Hour / 180 Minute Fire-Protective Glass: When used within size limitations, 180 minute, or 3-hour fire protective glass is approved for use in commercial window and door assemblies. Fire-protective glass is not a barrier to radiant heat.

Standards & Listings

Impact Safety Standard: CPSC 16CFR 1201 (CAT I & II)

Impact Safety Class: Tempered Glass 16CFR 1201 C-11 / ANSI Z97.1 2009A

Fire-Protective Glazing: ASTM E2074 | ASTM E-2010-01 | NFPA 80 | NFPA 252 | NFPA 257 | ULC CAN4-S104 | ULC CAN4-S106

  • Products classified by Underwriters Laboratories have been tested for fire-and impact resistance only.
  • UL9 Standard for Fire Tests of Window Assemblies
  • ANSI/UL10B Standard for Fire Tests of Door Assemblies
  • ANSI/UL10C Positive Pressure Fire Tests of Door Assemblies

Fire protective glazing materials are not a barrier to radiant or conducted heat. Fire protective products do not meet the heat resistance requirements of ASTM E119/UL 263. Use in fire-rated openings is limited to approved sizes. Use in architectural window openings with fire ratings of 60 minutes or greater may require approval from local building authorities.

Recommended Use

  • Commercial Door Windows: Vision lite and glass kits are meant for use in commercial windows and doors.
  • Impact-Safe Glass Doors: Tempered glass is recommended for use in areas prone to human impact.
  • Window Frames for Wood Doors: Metal door window kits are frequently used in commercial wood doors.
  • Door Vision Lite Kits: Add tempered or fire-rated windows to commercial wood and metal doors.
  • Fire-Rated Door Windows: Door window kits with fire-rated glass are approved for use in fire-rated doors.
  • Insulated Glass Door Lites: Insulated glass consists of 2 pieces of glass, sealed together with an air space between.
