18ga. Galvannealed Steel Embossed 1-Panel Commercial Door
18ga. Galvannealed Steel Commercial Doors with an embossed 1-panel design and a polystyrene core are designed for high use in commercial and industrial settings. The 1-panel design is ideal for situations where a more traditional look is desired while maintaining durability. These heavy-duty commercial doors offer exceptional performance and durability in both interior and exterior applications.
- Corrosion Resistant Galvannealed Steel
- Embossed 1-Panel Design
- Polystyrene Insulated Core
- Optional Fire Rating up to 3 Hours
- Standard and Custom Hardware Preps Available
Multiple Sizes Available
Product ID: S10-1P
FREE delivery to most businesses and jobsites on qualifying orders.
Most orders ship within 3-5 business days. Get a quote now.
HOW TO ORDER
- Get a written quote from a USA Fire Door Solutions Specialist
- Approve & we ship your order
- Click the button below or call us to get started. You can upload plans, photos or files if you have them.
Product Details
Hollow metal doors are constructed from high-quality galvannealed steel sheets formed, welded, and reinforced using interlocking seams to create a strong, durable and uncompromising door panel. These hollow metal doors come with an embossed 1-panel design and are ideal for situations where a more traditional look is desired. These hollow metal doors are finished with a factory applied, baked-on rust inhibiting primer providing a smooth finish and paintable surface suitable for commercial and industrial environments. They can be used in virtually any application for a dependable, reliable, and long-lasting solution whether it be interior or exterior and support standard or custom hinge and lock preparations. For more information, please speak to an Account Manager today!
Door Specifications
- Model shown with an embossed 1-panel design and a full body polystyrene core creating a flatter, stronger and smoother door
- For both interior and exterior applications
- Model shown with 161 “C” cylindrical lock prep. ANSI / SDI A115.2
- SDI Level 2: heavy duty 18-gauge corrosion resistant A40 galvannealed steel
- Meets or exceeds ANSI 250.4 and ANSI 250.8 standard
- Insulated cores to choose from – honeycomb, polystyrene, or polyurethane insulated cores (prices may vary)
- Factory applied 2-part epoxy primer for a superior finish, color gray. After cleaning, this door is ready to be finished with premium latex or oil-based paint
- Fire rated up to 3 hours and certified by WHI / ITS (Warnock Hersey / Intertek Testing Service) with positive pressure and “S” smoke ratings included.
- Additional features include a non-handed design, 12-gauge heavy duty closer reinforcement, 7-gauge heavy duty hinge reinforcement, 16-gauge heavy duty flush top cap, 16-gauge inverted bottom cap
- Sound transmission class (STC): 33
- Custom sizes and preparations available – please speak with an Account Manager today!
Lock Prep Options
161 Lock Prep / Deadbolt Prep
Bored – 2-3/4″ Backset (ANSI / SDI A115.2)
86 Edge Prep
Mortise Lock Edge Prep w/ Blank Face (ANSI / SDI A115.1)
RPD – Rim Panic Reinforced
(Blank Edge & Blank Face) Designed for use with panic bar exit devices.
Custom Lock Prep
(Template Required)
Configurations
Single Door
Double Door Active/Inactive
Secondary Door Can Open When Flush Bolts Are Disengaged
Double Exit Door
Both Doors Active w/ SVR Panic
Double Door Push/Pull
Both Doors Active
(Cannot Be Fire Rated)
Communicating Door
For Adjoining Hotel Rooms
Double Egress Door
For Emergency Exit In Either Direction
Double Acting Door
Swings Both Directions (Cannot Be Fire Rated)
Core Construction
Polystyrene – Provides improved thermal performance and rigidity
Thermal Performance
| U-Factor Range (Calculated) ASTM C518 | 0.13 to 0.16 |
| U-Factor Range (Operable) ASTM C1363 | 0.35 to 0.41 |
| R-Value Range (Calculated) ASTM C518 | 6.40 to 7.61 |
| R-Value Range (Operable) ASTM C1363 | 2.40 to 2.80 |
Disclaimer: Thermal performance data is based on industry standard construction methods and testing. Actual thermal performance may vary based on installation methods. The addition of weatherstrip, vision lites, glass, louvers and hardware products will affect thermal performance. Even though polystyrene offers greater thermal performance compared to other core options this product is not Energy Star qualified.
Standard Sizes
7’0” / 84” Door Heights (1-3/4” Thick)
| Nominal Size | Inches | Actual Size (Net) |
| 2’0” x 6’8” | 24” x 80” | 23-3/4” x 79-1/8” |
| 2’4” x 6’8” | 28” x 80” | 27-3/4” x 79-1/8” |
| 2’6” x 6’8” | 30” x 80” | 29-3/4” x 79-1/8” |
| 2’8” x 80” | 32” x 80” | 31-3/4” x 79-1/8” |
| 2’10” x 6’8” | 34” x 80” | 33-3/4” x 79-1/8” |
| 3’0” x 6’8” | 36” x 80” | 35-3/4” x 79-1/8” |
| 3’4” x 6’8” | 40” x 80” | 39-3/4” x 79-1/8” |
| 3’6” x 6’8” | 42” x 80” | 41-3/4” x 79-1/8” |
| 4’0” x 6’8” | 48” x 80” | 47-3/4” x 79-1/8” |
7’0” / 84” Door Heights (1-3/4” Thick)
| Nominal Size | Inches | Actual Size (Net) |
| 2’0” x 7’0″ | 24” x 84” | 23-3/4” x 83-1/8” |
| 2’4” x 7’0″ | 28” x 84” | 27-3/4” x 83-1/8” |
| 2’6” x 7’0″ | 30” x 84” | 29-3/4” x 83-1/8” |
| 2’8” x 7’0″ | 32” x 84” | 31-3/4” x 83-1/8” |
| 2’10” x 7’0″ | 34” x 84” | 33-3/4” x 83-1/8” |
| 3’0” x 7’0″ | 36” x 84” | 35-3/4” x 83-1/8” |
| 3’4” x 7’0″ | 40” x 84” | 39-3/4” x 83-1/8” |
| 3’6” x 7’0″ | 42” x 84” | 41-3/4” x 83-1/8” |
| 4’0” x 7’0″ | 48” x 84” | 47-3/4” x 83-1/8” |
8’0” / 96” Door Heights (1-3/4” Thick)
| Nominal Size | Inches | Actual Size (Net) |
| 2’0” x 8’0″ | 24” x 96” | 23-3/4” x 95-1/8” |
| 2’4” x 8’0″ | 28” x 96” | 27-3/4” x 95-1/8” |
| 2’6” x 8’0″ | 30” x 96” | 29-3/4” x 95-1/8” |
| 2’8” x 8’0″ | 32” x 96” | 31-3/4” x 95-1/8” |
| 2’10” x 8’0″ | 34” x 96” | 33-3/4” x 95-1/8” |
| 3’0” x 8’0″ | 36” x 96” | 35-3/4” x 95-1/8” |
| 3’4” x 8’0″ | 40” x 96” | 39-3/4” x 95-1/8” |
| 3’6” x 8’0″ | 42” x 96” | 41-3/4” x 95-1/8” |
| 4’0” x 8’0″ | 48” x 96” | 47-3/4” x 95-1/8” |
